      JDGT-R24 Roll Case Cake Cup Machine
      The JDGT-R24type machine is the latest model among our roll machines for the production of paper cups. we are absorbed the advantages of equipment in the United States, Italy and so on countries to build this kind machine.
      This machine is made up of completely mechanical movements in all its departments from the handling to the forming, from the unwinding to the advancement of the die-cutting step, and the precision is given by an innovative electronic control system that can be modified at any time by means of a PLC incorporated in the control panel .
      Main Technical Parameter:
      Mould JDGT—R24 roll case cake cup machine
      Setting mould area 2-4set mould (adjust by the paper size) 400*400mm
      Per mins forming paper 10-24piece
      Paper dia size 30---160MM
      Material 30---150gsm greaseproof paper , oil-protect paper pet paper
      Speed 25---35time/mins
      Air 0.1m3/min
      Power 3p 220/3p 380
      Total power 7KW
      Weight 4000KG
      Size 7000*1200*1900MM
